FC iFlight BLITZ Wing H743

BLITZ Wing H743 Flight Controller

The high-quality flight controller, designed specifically for Fixed Wing UAV enthusiasts, is compatible with INAV, and Ardupilot. With advanced features and compatibility with popular software platforms, BLITZ Wing H743 flight controller offers a superior flying experience, providing a reliable and efficient solution for the aircraft.

Features:

- Up to 5 groups of ESC power supply soldering pads.
- Equipped with dual analog camera input function, which can be switched by remote control.
- Independent 6A servo power supply BEC, providing powerful power protection for servos, compatible with servos of different voltages.
- Utilizes STM32H743 main MCU, offering powerful processing performance and feature support.
- Onboard SD card slot, providing large capacity storage space for data recording.
- Soldering pad reserved design.
- Onboard current meter, real-time monitoring of flight current.
- Supports external airspeed sensor for more accurate data.

Wiring Suggestion:
UART1 for VTX HD/Analog
UART2 for Receiver
UART4 for GPS
UART2, UART5, UART6, UART7 for free
5V 2.5A BEC for FC
9V 2.5A BEC for VTX
5-8.4V 6A BEC for Servo
