1700KV XING-E Pro 2306 2-6S FPV Motor

XING-E Pro series are very strong and powerful FPV motors for FPV racing. This 2306-sized motor features a high-strength 4mm steel hollow shaft, Single strand windings for performance, M3 shaft screw, and larger 9x4x4mm NSK bearings.

Features:

- High-strength 4mm Steel shaft
- N52SH High-temperature magnets, NSK bearings
- 16x16mm hole pattern
- Single-strand copper winding
- 6061 CNC machined aluminum top and base parts
- Hex bolt shaft set screw

Specifications

Model: XING-E Pro 2306 Motor
KV: 1750KV
Weight (including wire): 33.6g / 33.8g
Dimension: φ29*18.7mm
Interphase Resistance: 85.63mΩ / 55.6mΩ
Input Volts: 25.2V / 16.8V
Peak Current: 36.66A / 43.38A
Max Watt: 920.2W / 712.7W
Mounting Holes: 16*16 φ3mm
Rotor Specifications: Unibell
Shaft Diameter: 4mm
Shaft Protruding Length: 13.5mm
Lead: 160mm/20AWG
Magnet: N52H Curved
Configuration: 12N14P
Bearing Type: NSK
Bearing Specification: φ9*φ4*4
Winding: Single Strand copper winding

Includes

1 x XING-E Pro 2306 motor
4 x M3*8 Screws
1 x M5 Flanged Nylon Insert Lock Nut
